ZONCARE Medical Ultrasound Instruments Outstanding Portable Veterinary Ultrasound Scanner for Animals

ZONCARE Medical Ultrasound Instruments Outstanding Portable Veterinary Ultrasound Scanner for Animals Featured Image
  • ZONCARE Medical Ultrasound Instruments Outstanding Portable Veterinary Ultrasound Scanner for Animals
  • ZONCARE Medical Ultrasound Instruments Outstanding Portable Veterinary Ultrasound Scanner for Animals
  • ZONCARE Medical Ultrasound Instruments Outstanding Portable Veterinary Ultrasound Scanner for Animals
  • ZONCARE Medical Ultrasound Instruments Outstanding Portable Veterinary Ultrasound Scanner for Animals
  • ZONCARE Medical Ultrasound Instruments Outstanding Portable Veterinary Ultrasound Scanner for Animals
  • ZONCARE Medical Ultrasound Instruments Outstanding Portable Veterinary Ultrasound Scanner for Animals

Short Description:


  • Product Feature: High Quality Performance Professional Ultrasound Scanning Probe with Best Price with 12" Screen for Animal and Human Diagnosis with Medical Ultrasound Equipment for Abdominal, Obstetrics, Gynaecology, Urology, Cardiology, Small Parts with Multiple Imaging Mode B 2b 4b M B/m Pw Mode, can also be used for veterinary ultrasound, optional probe convex linear transvaginal

    • Product Detail

    Product Tags

    Overview
    Quick Details
    Place of Origin:
    China
    Brand Name:
    Amain
    Model Number:
    ZONCARE-i50
    Power Source:
    Electric
    Warranty:
    2 years
    After-sale Service:
    Online technical support
    Material:
    Metal, Plastic
    Shelf Life:
    2 years
    Quality Certification:
    CE ISO
    Instrument classification:
    Class II
    Safety standard:
    None
    Imaging mode:
    B, 2B/4B, M, B/M, PW
    Display:
    12 inch color display screen
    Transducer connectors:
    2 transducer connectors
    Resolution:
    1024 *768
    Tile Angle:
    0-90°
    Voltage:
    100-240V~
    Frequency:
    50/60Hz
    Gain:
    Adjust the whole image gain value
    Save:
    Save image/report
    Dimension:
    37*36*15.5 cm
    ZONCARE Medical Ultrasound Instruments Outstanding Portable Veterinary Ultrasound Scanner for Animals
    Specification
    item
    value
    Model
    ZONCARE-i50
    AC adapter Input
    Voltage: 100-240V~
    Frequency: 50/60Hz
    Power Consumption: 320VA
    Built-in Battery
    Lithium-ion rechargeable battery: 18650/6200mAh/66.9Wh
    Nominal voltage: 10.8V
    Limited charging voltage: 12.6V
    Imaging mode
    B, 2B/4B, M, B/M, PW
    Display
    12 inch color display screen
    Transducer ports and holders
    2 transducer ports
    2 removable transducer holders
    Clinical Applications
    Abdomen, Obstetrics, Gynecology, Urology, Cardiology, Small Parts,  Blood Vessel, Superficial, Thyroid, Galactophore,  Custom
    Resolution
    1024 *768
    Tile Angle
    0-90°
    Voltage
    100-240V~
    Frequency
    50/60Hz
    Gain
    Adjust the whole image gain value
    Save
    Save image/report
    Transducer Types
    Convex transducer,  Linear array, Trans-vaginal transducer, Micro-convex transducer
    Operation Environment
    Ambient temperature: 5 ℃~+40℃
    Relative humidity: 25%~85%
    Atmospheric pressure: 700hPa~1060hPa
    Storage &Transport Environment
    Ambient temperature: -20 ℃~+55℃
    Relative humidity: 10%~95%
    Atmospheric pressure: 500hPa~1060hPa
    Support Language
    Chinese, English, Spanish, French
    Net Weight
    6.2 kg
    Dimension
    37*36*15.5 cm
    Product Application
    i50 has excellent performance and different applications according to user's demands: Gynecology, Obstetrics, Abdomen, Urology, Vascular, Small parts, Orthopedic, Interventional etc.
    Product Features
    Features
    ●12-inch high resolution medical LCD monitor● Two transducer connectors● Auto-freezing function● Auto-generation BMP format report● Full screen imaging FSI● Q-Guide ● One key data storage● Multiple data transmission● Optional USB foot switch● Optional built-in battery● Optional customized trolley and suitcase● Transducers: Convex, Linear, Transvaginal, Micro-Convex

    Advanced Imaging Technologies

    * One Touch Optimization
    * Speckle Noise Reduction Imaging
    * Tissue Harmonics Imaging
    * Tissue Specific Imaging* PW Mode
    Certification
    Packing & Delivery
    Carton with protection.
